1900MHz Full Band Signal Booster, Signal Booster for Cell Phone Cell Phone Signal Booster, Mobile Signal Repeater

Item No.: TE1920
This is  mobile phone signal Booster TE1920 provides the ultimate solution in any area where cellular communications can not work well due to lack of signals.which ideal for house, home, office use.
Add to Inquiry
Description
1900MHz Full Band Signal Booster, Signal Booster for Cell Phone Cell Phone Signal Booster, Mobile Signal Repeater

TE1920 FullBand Mobile Signal Booster

Brief Description:
1900MHz Pico-Repeater is intended to strengthen the signal of  1900MHz mobile phone in the buildings. Ideal for use in areas where the 1900MHz signal is weak to cause Call dropout or Cant connection. The device improves the voice calls and data VOICE GPRS and EDGE (depends of the signal operator).

Features:
*High system gains.
*Full duplex and double-end design, external power supply, and convenient installation.
*ALC technology with auto-steady function adopted.
*Provide power indication and uplink and downlink indications.
*With the amplified linear power, the inter-modulation and spuriousness are suppressed effectively.
*The reliability conforms to GB6993-86 standards.
*The electromagnetic compatibility conforms to ETS300 609-4 standards.

Applicable place:
It can be applied in Building rooms there have weak signal of mobile.

Specification:
Frequency Range:
TE1920 Uplink:1850-1910MHz;Downlink:1930-1990MHz;
Gain:(dB) Uplink Gp: ≥65dB;   DownlinkGp:≥70dB;
Output Power(dBm):≥20dBm;
Pass band ripple PCS≤8dB;
Guard band rejection (BW-60dB):≤104MHz;  (BW-70dB)≤107MHz;
I/O Impedance: 50Ω/N Connector;
I/O Return loss: ≤-8dB;
Noise Figure: ≤-8dBm;
Inter-modulation attenuation(Po=13dBm): ≤-40dBm;
Transmission Delay: ≤0.5μs;
Ambient temperature: -10℃-50℃;
Power Supply: AC110-220V±10% /45-55Hz;
Size: 228mm×106m×33mm
Reliability: To the GB6993-86 standard
Electromagnetic compatibility: To the ETS300 694-4 standard

Function:
Power supply LED denote
b) Export power LED denote

Package contents:
1 pcs booster
1 set power supply
1 pcs user manual
1 set installation screws
