800W High power Jail Cellular Jammer Model:CPJ6022
Signal Booster

700MHz Te730 Full Band Mobile Signal Booster, GSM Booster

Item No.: TE730
The mobile signal booster is intended to strengthen the signal of
cellular signal booster.which is small size and easy to carry,built in power supply,suitable used for Hotels,Offices.
Add to Inquiry
4glte 700 Te730 Full Band Pico-Repeater, Mobile Radio Repeater, Mobile Signal Booster, Wireless Repeater, GSM Repeater

4GLTE 700 TE730 Full Band Pico-Repeater

Brief Description:
This model  signal booster 4glte700MHz,with an outdoor donor antenna could receive the signals and bring good signals in a relative good signal sources places and pass the signal to the amplifier and then spread it to where the
Signal is weak. Such as parking lots, basements, elevators and some hotels etc. These products need to be used in remote areas of the mountains.The machine can cover a range of 500-3000 square meters in some places where some signals are relatively simple.If the signal environment is not very good, the coverage area will be small.
Only amplifying the downlink signal will not effect on the operation of the base station.
*High system gains.
*Full duplex and double-end design, external power supply, and convenient installation.
*ALC technology with auto-steady function adopted.
*Provide power indication and uplink and downlink indications.
*With the amplified linear power, the inter-modulation and spuriousness are suppressed effectively.
*The reliability conforms to GB6993-86 standards.
*The electromagnetic compatibility conforms to ETS300 609-4 standards.
Applicable place:
It can be applied in Building rooms there have weak signal of mobile.
Frequency Range:
1. TE-730B (Uplink: 703-748MHz; Downlink: 758-803MHz);
1. TE-730B (Uplink)Gp≥75dB (Downlink) Gp≥80dB;
Outout Power
1. TE-730B ≥30dBm 1W;
Pass band ripple:≤4dB;
Guard band rejection: (BW-60dB)≤120MHz;
I/O impedance: 50Ω/N Connector;
I/O return loss: ≤-10dB;
Noise figure: ≤-8dB;
Inter-modulation attenuation(Po=13dBm):≤-40dBm;
Transmission: ≤0.5μs;
Ambient: -10℃-50℃;
Power Supply: AC110-220V±10%/45~55Hz;
Size: 350mm×230mm×60mm;
Weight: 4.5kg;
Reliability: To the GB6993-86 standard
Electromagnetic: To the ETS300 694-4 standard
a) Power supply LED denote
b) Export power LED denote
Package contents:
1 pcs booster
1 set power supply
1pcs user manual
1 set installation screws
