Shenzhen Vodasafe HD-R5 Portable Drone Detection and Positioning All-in-One Equipment
Description:
Developed by Shenzhen Vodasafe, the HD-R5 is a cutting-edge portable solution designed for intelligent drone surveillance and positioning. Engineered for security agencies, critical infrastructure protection, and event management, this all-in-one device combines passive detection, multi-target tracking, and precise identification to safeguard airspaces against unauthorized drone intrusions.
Features:
Passive Detection Technology
Receives electromagnetic signals without emitting any radiation, ensuring zero impact on the surrounding environment. Ideal for sensitive areas where signal interference is prohibited.
Comprehensive Tracking Capability
Simultaneously tracks trajectories of over 20 drones and 10 pilots (remote controls), displaying real-time flight paths and movement patterns on an integrated map.
Precision Identification
Accurately distinguishes drones by brand, model, frequency band, and unique electronic fingerprint ID (SN), even for devices of the same style and frequency band.
Cost-Effective Design
Single-unit operation with full functionality reduces deployment complexity. Supports standalone use or seamless integration with existing security systems.
Rapid Single-Device Positioning
Pinpoints drone and pilot coordinates, displaying distance, latitude/longitude, altitude, and working frequency band in real time.
User-Friendly Operation
One-click automatic detection and alarm system. Intuitive interface requires minimal training for immediate deployment.
Technical Performance
Detection Bands: 900MHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz (customizable)
Detection Radius: 0~5km+ (environment and drone-type dependent)
Airspace Coverage: 360° full-range detection
Simultaneous Targets: >20 drones, >10 pilot trajectories
Power Supply: Built-in lithium battery (12+ hours runtime) or mains input
Environmental Resistance: -40ºC~65ºC operating temperature, IP66 waterproof/dustproof
Advanced Specifications
| Frequency Range | 25MHz~6000MHz (customizable) |
| Detection Sensitivity | ≤-105dBm (at 1040MHz) |
| Positioning Accuracy | ≤1m (distance/height for drones), ≤1.5m (pilot distance), ≤0.5° (directional error) |
| Detection Success Rate | ≥99% under ideal conditions |
| False Alarm Rate | ≤1 per 24 hours in interference-free environments |
| Deployment Time | ≤90s (single-person setup), ≤20s (withdrawal) |
Drone Compatibility
The HD-R5 supports comprehensive detection of major brands, including:
DJI (Mavic, Air, Mini, Phantom, Inspire, etc.)
Autel, Hubsan, EHang, Yuneec, Xiaomi, Parrot, and over 30+ other manufacturers.
Rugged Reliability
Tested for harsh environments:
Electrostatic discharge immunity (contact: ±6kV, air: ±8kV)
Compliance with GB8702-2014 electromagnetic standards
Resistance to salt spray, vibration, and extreme temperatures (-40ºC-65ºC)
Applications
Airport and critical infrastructure security
Government facilities and event protection
Prison perimeters and sensitive research areas
Anti-drone defense systems for commercial and industrial sites
Shenzhen Vodasafe Commitment
As a leading provider of intelligent security solutions, Shenzhen Vodasafe ensures the HD-R5 combines cutting-edge technology with robust durability. Our product delivers unmatched performance in drone detection, setting new standards for portable airspace security worldwide.
For customization or technical inquiries, contact our team.
Note: Technical parameters are subject to change for product optimization. Refer to the latest datasheet for updates.
